(1) Part Name: SX25S004
(2) Module Size: 236.0(W) mm ´ 168.0(H) mm ´ 6.3 max (D) mm
(3) Display Size: Diagonal size 25cm (10.0")
(4) Dot Pitch: 0.0845(W) mm ´ 0.2535(H) mm
(5) Number of Dots: 800 ´ 3 (R,G,B)(W) ´ 600 (H) dots
(6) Duty: 1/300
(7) LCD: Film type (negative type)
The upper polarizer is an anti-glare type. (Hardness:3H)
(8) Viewing Direction: 12 O'clock
(9) Backlight: Cold Cathode Fluorescent Lamp (CFL) ´ 1
(10) Weight: (330) g
(11) Power Supply Voltage: 3.3V only
The SX25S004 is a cstn lcd panel.
SX25S004 absolute maximum ratings: (1)Power Supply for Logic, VDD-VSS: 0 to 4.6V; (2)Contrast Adjustment Voltage, VCON-VSS: 0 to VDD; (3)Input Voltage, Vi: -0.3 tp VDD+0.3V; (4)Input Current, Ii: 0 to 1A.
SX25S004 features: (1)Module Size: 236.0(W) mm×168.0(H) mm×6.3 max (D) mm; (2)Display Size: Diagonal size 25cm (10.0"); (3)Dot Pitch: 0.0845(W) mm×0.2535(H) mm; (4)Number of Dots: 800×3 (R,G,B)(W)×600 (H) dots; (5)Duty: 1/300; (6)LCD: Film type (negative type), The upper polarizer is an anti-glare type. (Hardness:3H); (7)Viewing Direction: 12 O’clock; (8)Backlight: Cold Cathode Fluorescent Lamp (CFL)×1; (9)Weight: (330) g; (10)Pow er Supply Voltage: 3.3V only.
******************************************************************
